ALWAYS READ THE LABEL AND FOLLOW THE DIRECTIONS FOR USE.Description AgeSmart™ Technology
Braun's AgeSmart™ colour-coded display takes the guess work out of interpreting temperature for the entire family. Simply use the AgeSmart™ button to select the appropriate age setting and take a temperature. A green screen suggests no fever, a yellow screen suggests moderate fever, and red signals high fever.
Fast and accurate due to Braun's patented satellite technology, the colour-coded screen also helps you decode readings instantly. Braun is the No.1 brand among consumers**.
**Helen of Troy’s calculation is based in part on data reported by Nielsen through its AOD Scantrack Service for the Thermometer category for the 52-week period ending November 24, 2018, for the Total U.S. xAOC channel, according to Helen of Troy’s custom product hierarchy. © 2018, The Nielsen Company.
Suitable For: Temperature measurement - forehead, object or liquid measurement
Suitable For: Temperature measurement - forehead, object or liquid measurement
Boxed Contents: Braun Touchless + Forehead Thermometer , Protective cap , 2 x AAA alkaline batteries
Warnings The thermometer and this guide are not intended as a substitute for consultation with your doctor.
If fever or complaints persist, consult your doctor.
Always read the label and follow the directions for use.
Ingredients N/A
Direction The Touchless + Forehead Thermometer has been clinically tested and proven accurate when used in accordance to the instructions.
1. Remove cap.
2. Power on: press and release the power button. Backlight will come on and the start up sequence begins.
3. Select age range with the AgeSmart™ button. Device will start cycling through the ages, keep pressing to toggle until you select the appropriate age.
4. When the device is ready and correctly positioned, a horizontal line of dashes (--) will appear on the screen.
5. Position device on, or up to 5cm away from the centre of the forehead, just between the eyebrows.
6. For No Touch readings, the yellow guidance light will show you where you are aiming.
7. When the device is placed correctly, the screen displays a dashed line animation while it takes the reading. If the device is positioned too far away from the forehead it will prompt you to move closer by displaying a diagram and the numbers 0-2.5cm. Slowly move the device towards the forehead until the dashed line animation (--) begins.
8. Press the temperature button (you can press and hold, or press and release).
9. After approximately 2 seconds, the display will show the temperature, including the corresponding beeps and fever traffic light colour.
NOTE: you can silence the beep function in order not to wake a sleeping child - refer to instruction booklet for details.
How to take food or bath temperature:
Follow instructions above, but at step 3, select 'Food & bath temperature mode' by pressing and releasing the food & bath mode button. A beep will sound, the food & bath icon will display and the screen backlight will be blue with three dashes, indicating it's ready.
Position the device up to 6cm away from the bath water or food. Aim directly at the food or liquid, not at the sides of the container holding it. Press the temperature button (press and hold, or press and release). The display will show the temperature reading.
Tips for taking temperature:
For best results the patient should be inside, away from direct sunlight for at least 30 minutes before taking temperature.
Remove any hair from forehead before measuring temperature.
Clean any sweat or dirt away from the forehead to improve accuracy.
Keep the patient's head still - it can help to have them look at a set point in the near distance.
Hold the thermometer steady while taking temperature - no need to 'swipe'.
Storage Instructions
When not in use, apply the protective cap to the Touchless + Forehead Thermometer.
For full instructions, care tips and troubleshooting please refer to the Instruction Manual
